中心传动刮吸泥机

产品概况：

   中心传动刮吸泥机由安装在中心支座上的驱动机构带动刮、吸泥收集装置，沿池径作圆周运动，池底的污泥依靠液体的静压作用，通过收集装置吸到污泥收集槽流入中心排泥管排出。上清液通过池周的溢流堰板流入集水槽，通过出水管排出。该机适用于中、大池径的辐流式沉淀池。

The central drive sludge scraper is driven by the driving mechanism installed on the central support to drive the scraping and suction sludge collection device, and makes a circular movement along the pool diameter. The sludge at the bottom of the pool depends on the static pressure of the liquid, and is sucked to the sludge collection tank through the collection device and flows into the central sludge discharge pipe. The supernatant flows into the catchment tank through the overflow weir plate around the tank, and is discharged through the outlet pipe. This machine is suitable for the radial flow sedimentation tank with medium and large diameter.

  产品特点 ：

 中心传动刮吸泥机由安装在中心进水柱管上的蜗轮减速电机驱动，通过中心回转支承的内啮合齿轮传动，带动框架钢结构、吸泥管臂架、集泥槽、吸泥管路、撇渣装置等部件转动，吸泥系统采用多根等距并列的吸泥立管将沉淀污泥经刮泥板导至吸泥管的吸口，靠静水压汇入集泥槽后排出池外的形式。

The central drive scraper is driven by a worm gear motor installed on the central water inlet column pipe, and driven by the internal meshing gear of the central slewing support to drive the frame steel structure, the mud suction pipe boom, the mud collection tank, the mud suction pipeline, and the slag skimming device. The mud suction system adopts multiple equally spaced parallel mud suction risers to guide the precipitated sludge to the suction port of the mud suction pipe through the mud scraper. The form is that it is merged into the mud collection tank by hydrostatic pressure and then discharged out of the tank.
